Slimx 120
Slimx 120 Specs
Slimx 120
Image Sensor
Resolution
4096 x 3072
Native Frame Rate
300 Hz
Latency
3.3 ms
Tracking Performance & Range
3D Accuracy
0.1 mm
Active Distance
91 m (299′)
Passive Distance
Filter & Lens
Filter Switcher
Optional
Filter
Adjustable Focus
Adjustable F-Stop
Stock Lens
C-Mount 24mm f/1.6 Lens
Optional Lens
C-Mount 18mm f/1.6 Lens
Global Shutter
Default Speed
0.25 ms
Minimum Speed
0.01 ms
Maximum Speed
2.5 ms
Image Processing
Object
Raw Grayscale
MJPEG Grayscale
Duplex Mode
Full Resolution MJPEG
Segment
Connections
Data Port
GigE
Camera Sync Port
Ethernet
Power Port
PoE+
LED Ring
Number of LEDs
LED Wavelength
LED Output
Size & Weight
Width
4.49 in (11.4 cm)
Height
4.49 in (11.4 cm)
Depth
6.07 in (15.42 cm)
Weight
2.8 lbs (1.27 kg)
Camera Body
Camera Body
Aluminum & Polycarbonate
Mount Type
1/4-20 Standard Tripod Mount (x2)
Status Indicator Type
3 digit numeric LEDs status indicators
LED Activity Type
Single LED
